Description: |
IC SWITCH SP4T X 2 200OHM 16SOIC |
Digi-Key Part Number: |
505-ADG1209YRZ-REEL7TR-ND |
Manufacturer: |
Analog Devices Inc. |
Manufacturer Product Number: |
ADG1209YRZ-REEL7 |
Detailed Description: |
2 Circuit IC Switch 4:1 200Ohm 16-SOIC |
Product Status: |
Active |
Description: |
IC SWITCH SP4T X 2 200OHM 16SOIC |
Digi-Key Part Number: |
505-ADG1209YRZ-REEL7TR-ND |
Manufacturer: |
Analog Devices Inc. |
Manufacturer Product Number: |
ADG1209YRZ-REEL7 |
Detailed Description: |
2 Circuit IC Switch 4:1 200Ohm 16-SOIC |
Product Status: |
Active |
ADG1209YRZ-REEL7 New And Original Integrated Circuit Ic Chip Memory Electronic Modules Components
Find information here in stock.xlsx
Product Attributes
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches, Multiplexers, Demultiplexers | |
| Mfr | Analog Devices Inc. |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Switch Circuit | SP4T |
| Multiplexer/Demultiplexer Circuit | 4:01 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 200Ohm |
| Channel-to-Channel Matching (ΔRon) | 3.5Ohm |
| Voltage - Supply, Single (V+) | 5V ~ 16.5V |
| Voltage - Supply, Dual (V±) | ±5V ~ 16.5V |
| Switch Time (Ton, Toff) (Max) | 95ns, 100ns |
| -3db Bandwidth | 550MHz |
| Charge Injection | 0.4pC |
| Channel Capacitance (CS(off), CD(off)) | 1.5pF, 4.5pF |
| Current - Leakage (IS(off)) (Max) | 100pA |
| Crosstalk | -85dB @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | ADG1209 |
| RESOURCE TYPE | LINK |
| Datasheets | ADG1208,09 |
| Other Related Documents | Programmable Gain Instrumentation Amplifiers: Finding One that Works for You |
| Tape and Reel Packaging | |
| Product Training Modules | Switch Fundamentals |
| Design Resources | Parametric Measurement Unit and Supporting Components for PAD Appls Using AD5522 and AD7685 (CN0104) |
| Featured Product | Analog Devices IoT and the Intelligence of Things |
| Sensor Signal Chain | |
| Analog Devices' Wireless Sensor Networks | |
| EDA Models | ADG1209YRZ-REEL7 - Models |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | ADG1209YRZ-REEL7DKR |
| ADG1209YRZ-REEL7TR-ND | |
| ADG1209YRZ-REEL7CT | |
| ADG1209YRZ-REEL7TR | |
| ADG1209YRZ-REEL7DKR-ND | |
| 505-ADG1209YRZ-REEL7DKR | |
| ADG1209YRZ-REEL7-ND | |
| 505-ADG1209YRZ-REEL7TR | |
| 505-ADG1209YRZ-REEL7CT | |
| ADG1209YRZ-REEL7CT-ND | |
| Standard Package | 1,000 |
